General Specs |
| Color | Custom |
| Color/Finish Name | Panel Ready |
| Dishwasher Type | Built-In |
| Number of Cycles | 7 |
| Control Panel Type | Top |
| Tub Material | Stainless Steel |
| Handle Type | Panel Ready |
| Door Panel Type | Panel |
| Noise level (dB) | 42 |
| Sound Rating Range | Quietest |
| Dishwasher Features | Cutlery Holder, Steam Option, Door/Child Lock, Food Disposal, Sensor Wash, Wi-Fi Capable, Adjustable Rack, Automatic Temperature Control, Silverware Jets, Tall Tub, App Capable |
| Third Rack | Yes |
| Sanitize Option | Yes |
| Custom Panel Ready | Yes |
| Water Softener | No |
| Delay Wash (Up to hours) | 12 |
| Number Of Place Settings | 16 |
| Smart Compatible | Yes |
| Appliance Fit Width (in.) | 24 |
| Width (in.) | 23.75 |
| Depth (in.) | 24 |
| Depth w/Door Open 90 Degrees (in.) | 25.5 |
| Height (in.) | 34 |
| Product Weight (lbs.) | 126 |
| Cut Out Width | 24 |
| Cut Out Depth | 24 |
| Cut Out Height | 33.5 |
| Manufacturer Warranty | 2 Year Limited Parts & Labor |
| ENERGY STAR Certified | Yes |
| ADA Compliant | No |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 10.2 |
Overview |
| Control Type | Electronic Tactile Buttons Top Controls |
| Dishwasher Control Features | Audible End-of-Cycle Signal
Hi-Resolution Gray Scale LCD Control Display
Last Cycle Memory |
| Wash System | 900 Series |
| Wash System Features | 90+ Spray Jet Wash System
Automatic Temperature Control
Bottle Wash Jets
Dedicated Silverware Jets
Deep Clean Silverware Jets
Hard Food Disposer with removable filter
Hidden Heater
Middle Wash Arm
Reversing Blade Lower Wash Arm
Variable Speed Dual Pumps and Motors |
| Sensor | Clean Sensor |
| Wash Arms | 3 Pressurized Wash Arms
90+ Spray Jet Wash System
Bottle Wash Jets
Jets - Variable Pressure
Lower - Reversing Blade
Middle - Blade
Silverware Wash Jets |
| Water Filtration System | 100% Filtration with Hard Food Disposer and Removable Filter |
| Dispenser | Electronic Low Rinse Aid Sensor
Rinse Aid with Indicator and Adjustment |
| Dishwasher Cycles | 30 Min Wash
Auto Wash
Delicate
Eco Wash
Intense
Normal
Rinse |
| Number of Options | 11 |
| Dishwasher Options | Bottle Wash
Child Lock
Delay Start 1-12 Hr.
Heated Dry
Pre Soak
Sani (NSF 184 Certified)
Start/Reset
Wash TempBoost
Wash Zone Lower Only
Wash Zone Upper Only |
| Rack Features | 2 Fold-Down Tines - Lower
2 Utility Shelves with 2 Stem Safe - Upper
3 Piece Silverware Basket with Soft Touch Handle
Adjustable Upper Rack
Ball-Tipped Tines |
| Racking System | Full 3rd rack |
| Rack Color | Silver |
| Upper Rack | 1 Rack handle
1/2 fixed tines, 1/2 fold down tines
2 Stem Safe Shelves
Ball-Tip Tines
Premium Height Adjustable |
| Lower Rack | 1 Rack handle
Ball-Tip Tines
Multi-Position Fold Down Tines |
| Cutlery Tray | Full 3rd rack (above upper rack) |
| Dishwasher Drying Features | 2 Fans/Extra Heater
Fan Dry On/Off plus Max Dry |
| Interior Lighting | LED |
| Leveling System | Front Adjustable Leveling Legs |
| Latch | Pull with Handle |
| Sabbath/Door Wakeup Mode | Yes |
| Connected Capabilities | Amazon Alexa
Amazon Dash Replenishment
IFTTT
The Google Assistant |
| Custom Panel Ready | 3/4-Inch Overlay Panels |
Dimensions |
| Height w/ Legs Retracted - Minimum Height | 33 3/8 in |
| Height w/Legs Extended - Maximum Height | 34 5/8 in |
Power / Ratings |
| Calrod Heater Watts | 1200 |
